Shower Application

Shower

Shower @ 2 GPM
Choose Incoming Water Temp
Outlet Temp: 104°F

ModelActivationPhaseVoltsKWAmps/Ø75°C Wire
ER-90L/2080.35 GPMSingle20818.790(3x30)10 AWG
ER-90L/2400.35 GPMSingle24021.690(3x30)10 AWG
R-68L/2770.35 GPMSingle27718.85684 AWG
ModelActivationPhaseVoltsKWAmps/Ø75°C Wire
ER-90L/2080.35 GPMSingle20818.790(3x30)10 AWG
R-75L/2400.35 GPMSingle24018754 AWG
R-63L/2770.35 GPMSingle27717.45634 AWG
ModelActivationPhaseVoltsKWAmps/Ø75°C Wire
R-75L/2080.35 GPMSingle20815.6754 AWG
R-68L/2400.35 GPMSingle24016.3684 AWG
R-58L/2770.35 GPMSingle27716.05586 AWG
ModelActivationPhaseVoltsKWAmps/Ø75°C Wire
R-75L/2080.35 GPMSingle20815.6754 AWG
R-63/2400.35 GPMSingle24015.1634 AWG
R-58L/2770.35 GPMSingle27716.05586 AWG
ModelActivationPhaseVoltsKWAmps/Ø75°C Wire
R-68L/2080.35 GPMSingle20814.15684 AWG
R-58L/2400.35 GPMSingle24013.9586 AWG
R-48L/2770.35 GPMSingle27713.3486 AWG

Resources

Submittal Triplets High Capacity Heater - Low Activation, 90 to 120 AmpHigh Capacity, Low Activation - 90 to 120 AMPView
Submittal R Series Water Heater - Low ActivationMIGHTY-mite® High Capacity Tankless Water Heaters- 10 to 20 Kilowatts, Low Activation including R-48L/208, R-48L/240, R-58L/208, R-63L/208, R-48L/277, R-58L/240, R-68L/208, R-63L/240, R-75L/208, R-58L/277, R-68L/240, R-63L/277, R-75L/240 and others.View
